STANDARD TRI-CLAMP FITTINGS 3A SANITARY FERRULES

TRI-CLAMP FITTINGS SANITARY FERRULES
304 Stainless 304 Stainless
hose part list hose ferrule part list
size number each size i.d. number each
1 TC-4C 77.34 1 1-32/64 SAN100132 55.64
1-1/2 TC-6C 91.94 1 1-38/64 SAN100138 55.64
2 TC-8C 149.07 1 1-44/64 SAN100144 55.64
2-1/2 TC-10C 207.75 1 1-50/64 SAN100150 55.64
3 TC-12C 300.07 1-1/2 2-4/64 SAN150204 63.57
1-1/2 2-10/64 SAN150210 63.57
1-1/2 2-16/64 SAN150216 63.57
TRI-CLAMP REDUCERS 1-1/2 2-20/64 SAN150220 63.57
2 2-40/64 SAN200240 82.65
304 Stainless 2 2-44/64 SAN200244 82.65
hose part list 2 2-50/64 SAN200250 82.65
size number each 2 2-56/64 SAN200256 82.65
1-1/2 X 1 TCR-6X4C 76.41 2-1/2 3-12/64 SAN250312 198.67
2-1/2 3-18/64 SAN250318 198.67
2-1/2 3-24/64 SAN250324 198.67
3 3-40/64 SAN300340 214.57
3 3-48/64 SAN300348 214.57
WASHDOWN SWIVELS 3 3 3-52/64 SAN300352 214.57
3-60/64
SAN300360
214.57
3 4 SAN300400 214.57
4 4-52/64 SAN400452 POR
4 5-6/64 SAN400506 POR

WASHDOWN SWIVEL
300 Stainless
npt part list
size number each
1/2 x 1/2 WDSS-2 80.56
1/2 x 3/4 WDESS-2X3 83.90
1/2 x 5/8 WDESS-2X58 84.06
