G Sanitary, Washdown, and PCT Couplings for Food and Beverage

Campbell Crimpnology™ offers hose CRIMPNOLOGY TRI-CLAMP GASKETS
assembly systems for all your 3A TRI-CLAMP Features & Benefits
food grade hose applications!
FITTINGS, • Materials compliant with FDA
ADAPTERS & Code of Federal Regulations under
FERRULES Title 21.
Features & Benefits TRI-CLAMPS
• Campbell Crimpnology™ offers
hose assembly systems for food Features & Benefits
grade hose applications. • Designed for use with any
• Specially designed shank & ferrule Tri-Clamp fittings and adapters.
lengths are matched for hose tube
and cover protection. PROTECTIVE BUMPER
• Dedicated silicone bumper seat Features & Benefits
area on crimp hose fittings. • Fits into machined recessed
• All products listed as 3A bumper area on all Campbell
components are certified to meet Tri-Clamp Crimp Hose Fittings.
32 Ra minimum polish and all other • Easy on/off installation.
3A criteria under 3A RPSCQC. • Manufactured from FDA
• Crimp specifications are approved silicone.
provided for all hoses for proven
performance (3A crimp process WASHDOWN SWIVELS
exception).
Features & Benefits
• 360° swivel rotation between
Campbell Sanitary the threaded hex and hose barb
serration pattern
for easy installation and smooth
swiveling during wash down,
eliminates hose kinking.
Ferrule interlock groove • Manufactured with 300 Series
(for standard ferrules or stainless steel
machined ferrules)
Ferrule groove CRIMPNOLOGY
Bumper location WINE FITTINGS
(with Pacific Coast Threads - PCT)
Tri-Clamp end Features & Benefits
• Crimp specs and procedures
provided for all styles.
• For use with Campbell ferrules and
sleeves or band clamps.
TESTING

All Campbell products are thoroughly tested to determine accurate performance data, such as
pressure ratings and temperature derating data. See example of Tri-Clamp hydrostatic test below.

Hose: 1” ContiTech Grey Vintner
Working Pressure: 250 psi
Test temp: 70°F
Highest Test Pressure: 2039 psi.
Failure Mode: Hose burst beyond 8x WP

MAX. SYSTEM WORKING PRESSURE (PSI @ 70°F) SEE NOTE 1
Hose System Componenets Hose Size
Fitting/Coupling Attachment Hose Type 1 1-1/4 1-1/2 2 2-1/2 3 4
Tri-Clamp Ferrule Sanitary 500 - 450 350 325 300 call
Tri-Clamp Mach. Ferrule Sanitary 500 - 500 400 375 350 call
Wine Fitting Ferrule Sanitary - - 450 350 - 300 -
42 Wine Fitting Band Clamps Sanitary - - 100 100 - 50 -
See footnotes 1 and 2 on Page 1
