3A FITTINGS & ADAPTERS TRI-CLAMP X MALE NPT
316 Stainless
npt part list
size number each
1 X 3/4 TCM-4X3 316 105.97
1 X 1 TCM-4 316 105.97
1-1/2 X 1-1/2 TCM-6 316 105.97
1-1/2 X 2 TCM-6X8 316 143.80
2 X 1-1/2 TCM-8X6 316 143.80
2 X 2 TCM-8 316 148.33
2-1/2 X 2 TCM-10X8 316 189.20
2-1/2 X 2-1/2 TCM-10 316 208.87
3 X 2 TCM-12X8 316 280.03
3 X 3 TCM-12 316 280.03
4 X 4 TCM-16 316 302.73

TRI-CLAMP X FEMALE NPT

316 Stainless
3A TRI-CLAMP CRIMP HOSE FITTINGS npt part list
size number each
316 Stainless 1 X 3/4 TCF-4X3 316 86.30
hose part list 1 X 1 TCF-4 316 105.97
size number each 1-1/2 X 1-1/2 TCF-6 316 112.03
1 TC-4C A316 85.43 1-1/2 X 2 TCF-6X8 316 148.33
1-1/2 TC-6C A316 87.43 2 X 1-1/2 TCF-8X6 316 98.37
2 TC-8C A316 152.59 2 X 2 TCF-8 316 148.33
2-1/2 TC-10C A316 278.14 2-1/2 X 2 TCF-10X8 316 148.33
3 TC-12C A316 341.74 2-1/2 X 2-1/2 TCF-10 316 227.03
4 TC-16C A316 POR 3 X 2 TCF-12X8 316 227.03
1-1/2 x 1 TCR-6X4C A316 97.45 3 X 3 TCF-12 316 264.90
4 X 4 TCF-16 316 284.57

3A LONG SHANK BREWERY 3A TRI-CLAMP X WELD SHORT
HOSE ADAPTER
316 Stainless
304 Stainless hose part list
hose part list size number each
size number each 1/2 TCSW-2 316 9.83
1 BATC-4 304 62.00 3/4 TCSW-3 316 9.83
1-1/2 BATC-6 304 73.90 1 TCSW-4 316 9.83
2 BATC-8 304 79.47 1-1/2 TCSW-6 316 9.83
3 BATC-12 304 109.67 2 TCSW-8 316 11.37
4 BATC-16 304 174.87 2-1/2 TCSW-10 316 18.17
3 TCSW-12 316 22.33
4 TCSW-16 316 32.57
3A RUBBER HOSE ADAPTER
316 Stainless 3A TRI-CLAMP X WELD LONG
hose part list
size number each 316 Stainless
1 X 1/2 RATC-4X2 316 62.00 hose part list
1 X 3/4 RATC-4X3 316 62.00 size number each
1 X 1 RATC-4 316 62.00 1/2 TCLW-2 316 12.27
1-1/2 X 1/2 RATC-6X2 316 73.90 3/4 TCLW-3 316 12.27
1-1/2 X 5/8 RATC-6X58 316 73.90 1 TCLW-4 316 14.77
1-1/2 X 3/4 RATC-6X3 316 73.90 1-1/2 TCLW-6 316 14.77
1-1/2 X 1 RATC-6X4 316 73.90 2 TCLW-8 316 16.63
MAX. SYSTEM WORKING PRESSURE (PSI @ 70°F) SEE NOTE 1 1-1/2 X 1-1/2 RATC-6 316 73.90 2-1/2 TCLW-10 316 25.73
79.47
RATC-8X6 316
2 X 1-1/2
Hose System Componenets Hose Size 2 X 2 RATC-8 316 79.47 3 4 TCLW-12 316 29.90
43.17
TCLW-16 316
Fitting/Coupling Attachment Hose Type 1 1-1/4 1-1/2 2 2-1/2 3 4 2-1/2 X 2-1/2 RATC-10 316 79.47
3 X 3 RATC-12 316 109.67
Tri-Clamp Ferrule Sanitary 500 - 450 350 325 300 call 4 X 4 RATC-16 316 174.87
Tri-Clamp Mach. Ferrule Sanitary 500 - 500 400 375 350 call
Wine Fitting Ferrule Sanitary - - 450 350 - 300 -
Wine Fitting Band Clamps Sanitary - - 100 100 - 50 - 43
