hose ferrule part list 2-1/2 3-8/64 FPS250308L 33.41
size i.d. number each 2-1/2 3-12/64 FPS250312L 33.41
4 4-56/64 FSS400456 76.11 2-1/2 3-16/64 FPS250316L 33.41
4 4-60/64 FSS400460 76.11 2-1/2 3-20/64 FPS250320L 33.41
4 5 FSS400500 76.11 2-1/2 3-28/64 FPS250328L 33.41
4 5-4/64 FSS400504 76.11 3 3-36/64 FPS300336L 33.62
6 6-56/64 FSS600656 95.28 3 3-40/64 FPS300340L 33.62
6 7 FSS600700 95.28 3 3-44/64 FPS300344L 33.62
6 7-8/64 FSS600708 95.28 3 3-48/64 FPS300348L 33.62
6 7-24/64 FSS600724 95.28 3 3-52/64 FPS300352L 33.62
8 FSS800XXX POR 3 3 3-56/64 FPS300356L 33.62
FPS300360L
33.62
3-60/64
Plated Steel Heavy Duty 3 4 FPS300400L 33.62
(for 206S & FRAC-16C fittings only) 3 4-8/64 FPS300408L 33.62
4 4-48/64 FPS400448F 41.36 3 4-16/64 FPS300416L 33.62
4 4-52/64 FPS400452F 41.36 4 4-40/64 FPS400440L 47.06
4 4-56/64 FPS400456F 41.36 4 4-44/64 FPS400444L 47.06
4 4-60/64 FPS400460F 41.36 4 4-48/64 FPS400448L 47.06
4 5 FPS400500F 41.36 4 4-52/64 FPS400452L 47.06
4 5-4/64 FPS400504F 41.36 4 4-56/64 FPS400456L 47.06
4 4-60/64 FPS400460L 47.06
4 5 FPS400500L 47.06
4 5-4/64 FPS400504L 47.06
FERRULES 4 4 5-12/64 FPS400512L 47.06
FPS400520L
47.06
5-20/64
for use with products shown below: 4 5-28/64 FPS400528L 47.06
WARNING: NOT FOR USE WITH STEAM
LIGHT DUTY
Viton Seal
®
Long Ground FERRULES
Crimpnology Joints and
Nipples Male Stems
Section B Section D
Plated Steel
hose ferrule part list
size i.d. number each
1/2 1 FPS050100S 11.61
1/2 1-4/64 FPS050104S 11.61
1/2 1-8/64 FPS050108S 11.61
3/4 1-16/64 FPS075116 10.00
3/4 1-20/64 FPS075120 10.00 LIGHT DUTY FERRULES
3/4 1-24/64 FPS075124 10.01 for use with couplings shown below:
3/4 1-28/64 FPS075128 10.01
3/4 1-32/64 FPS075132 10.01
1 1-32/64 FPS100132 10.01
1 1-36/64 FPS100136 11.60
1 1-40/64 FPS100140 11.60 All
1 1-44/64 FPS100144 11.60 Campbell Single-Lock Double-Lock
1 1-48/64 FPS100148 11.60 Universals UniversaLock (Bowes) (Thor)
1 1-52/64 FPS100152 11.60 Section E Section E Section E Section E
1-1/4 1-52/64 FPS125152L 11.60
1-1/4 1-56/64 FPS125156L 11.91
1-1/4 1-60/64 FPS125160L 16.86
1-1/2 1-60/64 FPS150160L 16.86 Plated Steel
1-1/2 2 FPS150200L 16.86 hose ferrule part list
1-1/2 2-4/64 FPS150204L 20.17 size i.d. number each
1-1/2 2-8/64 FPS150208L 20.17 1/2 58/64 FLPS050058 1.50
1-1/2 2-12/64 FPS150212L 20.17 1/2 60/64 FLPS050060 1.50
1-1/2 2-16/64 FPS150216L 20.17 3/4 1-8/64 FLPS075108 1.94
1-1/2 2-20/64 FPS150220L 20.17 3/4 1-10/64 FLPS075110 1.94
1-1/2 2-24/64 FPS150224L 20.17 3/4 1-12/64 FLPS075112 1.94
2 2-32/64 FPS200232L 20.17 3/4 1-14/64 FLPS075114 1.94
2 2-36/64 FPS200236L 20.17 3/4 1-16/64 FLPS075116 1.94
2 2-40/64 FPS200240L 24.29 3/4 1-18/64 FLPS075118 1.94
2 2-44/64 FPS200244L 24.29 1 1-28/64 FLPS100128 3.00
2 2-48/64 FPS200248L 24.29 1 1-30/64 FLPS100130 3.00
2 2-52/64 FPS200252L 24.29 1 1-32/64 FLPS100132 3.00
2 2-56/64 FPS200256L 24.29 1 1-34/64 FLPS100134 3.00
50 2 2-60/64 FPS200260L 24.29 1 1-36/64 FLPS100136 3.00
